WARNING:

Designs featured on this page were created by our guest designers and may not be fully articulated or tested for compatibility with the 5.5" range of figures.

Some of these designs have been modified by me with permission of the artist (typically to add articulation, extra bells and whistles, and/or make them slightly more screen accurate or easier to print) and are listed as "Remix" figures.

The same rules that apply to my own designs also apply to all other figures and props. They are not to be reposted to other sites or printed and sold for financial gain without the express permission of the original creator (most of whom can be contacted via our Facebook Group.)


If you aren't sure what this means, read the F.A.Q. page, contact me on Facebook, or just assume that if you are requesting money for any product constructed using these designs, you are breaking the rules and DON'T DO IT!
All it takes is one greedy person to ruin the fun for everybody.


If you are an artist and would like to submit 3D printable files for inclusion on this website, please contact Troy Wood via the 3D Printing Doctor Who Facebook Group or tag @troyryanwood on instagram. Please understand that we're only interested in sharing professional quality finished files in STL or OBJ format that are ready for 3D printing.

Guest designs can be based on anything from both the old and new series of Doctor Who, including it's spin-offs (official or otherwise), the Peter Cushing movies, Big Finish audio plays, comics, annuals, novels, Blue Peter contests, board games, ice lolly packets, Weetabix cards.... anything that can be obviously recognized as being Doctor Who-related, provided it's family friendly.

While it's nice if you can scale your designs to match one of the existing toy ranges, this is not required. They can be any scale or size, hyper-realistic or stylized, articulated or a solid statue. If you do scale your design to a particular range, let me know which one so I can categorize it correctly.

Do not submit partially completed works in progress, duplicates of existing figures/accessories in the Character Options toy range (even if they're out of print), designs created by other artists (unless you have their permission) or
random household objects like keychains and drink coasters that you've simply slapped the Doctor Who logo onto (there are plenty of those up on Thingiverse, if you want to search for them.)


Figures and play sets in scale with the existing 5.5" Character Options range of figures that I have personally remixed to be fully articulated and/or add other improvements.

REMIX001
Battle Damage Emperor Dalek
REMIX002
Kronos (Chronovore)
REMIX003
Meddling Monk and TARDIS

REMIX004
Key To Time and Tracer




Figures, play sets, and set pieces in scale with the existing 5.5" Character Options range of figures.
These figures have been designed by other artists and may or may not be articulated. Expect some of these to eventually make it into the REMIX section above.

Classic 60's TARDIS Interior Play Set Secondary Console Room TARDIS Console Rani's TARDIS
from Mark of the Rani
Zero Room Play Set
from Castrovalva
"Hudolin" 8th Doctor
TV Movie TARDIS
"Brachaki" 1st Doctor
TARDIS
Emperor Dalek
from TV 21 Comics
Astral Map
from The Web Planet
Time-Space Visualizer
from The Chase
Tomb of the Cybermen
Play Set
Dalek City Play Set The Whomobile
from Planet of the Spiders
Absorbaloff
from Love & Monsters
Chameleon
from The Faceless Ones (animated)
Draconian
from Frontier in Space
Cyber Warrior
from Ascension of the Cybermen
Cyber Master
from The Timeless Children
Dalek Trooper
from Resurrection of the Daleks
The Destroyer and
Knight Commander

from Battlefield
Ice Lord
from Monster of Peladon
Kronos
from The Time Monster
"Nightmare" Cyberman
from Nightmare in Silver
"Wheel" Cyberman
from Wheel in Space
Peter Cushing "Dr. Who"
from the Dalek movies
Sontaran Steg
from Shakedown: Return
of the Sontarans (spin-off)
The Lone Cyberman
from The Haunting of Villa Diodati
Blackpool Exhibition
Entrance TARDIS
Golden Emperor Dalek
from Timelord Victorious (animated)
Mr. Smith
from Sarah Jane Adventures
Proposed Season 27
TARDIS Console Room
TT Capsule (without
Chameleon Circuit)
from Hell Bent
The Rani's TARDIS Console
from Mark of the Rani
Dalek Transmat
from Evil of the Daleks
The Moment (Button)
from Day of the Doctor
Kasaavin
from Spyfall
The General
from Day of the Doctor
and Hell Bent
Baltazar
from The Inifinite Quest (animated)
Barnabus
from TV-21 Comics
The Trods
from TV Comics
Emperor Dalek
Throne Room Play Set

from Evil of the Daleks
The Slyther
from The Dalek Invasion of Earth
The Trickster
from Sarah Jane Adventures
Trantis
from Mission to the Unknown
The Kandyman
from The Happiness Patrol
Dinosaur Stun Gun
from Invasion of the Dinosaurs
13th Doctor TARDIS
Console Room
Kamelion
from The King's Demons
and Planet of Fire

The Anne Droid
from Bad Wolf and
Parting of the Ways

Trin-R and Zu-Zanna
from Bad Wolf and
Parting of the Ways
Dalek Control Panels
from Mission to the Unknown
Sontaran Scout Ship
from The Time Warrior
Season 13 Sontaran
from War of the Sontarans
Spiridon Temple Entrance
from Planet of the Daleks
Snowman
from The Snowmen
"The Flood" Cyberman
and Cybercontroller

from The Flood (comic)
"Lost Warriors" Cyberman
from Lost Warriors (audio)
Malpha
from The Daleks' Master Plan
Warrior Sea Devil
from Warriors of the Deep
Cyber Console
from Earthshock
Hyperspacial Bridge Device
from Stones of Blood


Custom parts and accessories used for converting or enhancing existing 5.5" scale Character Options figures.

Troy's Miscellaneous Customizing Parts

The Valeyard (Head Only)
Adric (Head Only)
1970's Newbery TARDIS Base
1970's Newbery TARDIS Top
1980's Yardley TARDIS Base
Movie/Supreme Dalek bumper (solid)
Movie/Supreme Dalek bumper with holes for Lego wheels
Modern Dalek Bumper
Custom Sontaran Helmet (no eye holes)

The Trickster Head
from Sarah Jane Adventures
Movie Dalek Claw
from the Dalek movies
Timelord Victorious
Dalek Parts

from Timelord Victorious (animated)
New Series
Dalek Parts

Classic Series Dalek
Parts and Accessories
'Carnival' Auton Heads
from Terror of the Autons
Replacement K-1 Robot
Foot Part

from Robot
Kraal Android Head
from The Android Invasion
Sentreal Head
from Mission to the Unknown
Sontaran Rifle
from The Two Doctors
Cyberman Head
from Sword of Orion (audio)
Bus Conductor Head
from Greatest Show in the Galaxy
Commander Maxil Body
from Arc of Infinity
Time Lord Collar
from Various
Rapid-Fire Dalek Gun
from Eve of the Daleks
Kane Head
from Dragonfire
Alex Macqueen
Master Head

from UNIT: Dominion (audio)
Movie Dalek
Customizing Parts

from the Dalek movies
3rd Doctor
Accessory Pack

from Various
Death Zone Torch
from The Five Doctors



Figures, parts, and other miscellaneous items that don't fit the standard 5.5" scale Character Options range of figures.

Palitoy Talking Dalek
Replacement parts

1:6 Scale
3rd Doctor Head

1:6 Scale
Tloxtl Head

from The Aztecs
1:6 Scale
Mavic Chen Head

from The Daleks' Master Plan

1:6 Scale
Meddling Monk Head

from The Time Meddler



Replica props and costume pieces for all your cosplay needs.

Missy's Gadget
from Death In Heaven
Romana's Sonic Screwdriver
from The Horns of Nimon
Metebelis III Crystal
from The Green Death
and Planet of Spider
Rose Tyler Dalek Blaster
from The Stolen Earth
Full-Sized New Series Dalek 6th Doctor's Sonic Lance
Romana I's Dress Clasp
from The Ribos Operation
Gallifreyan Staser Rifle
from Day of the Doctor/Hell Bent
Cyberman Gun
from Earthshock/The Five Doctors/
Attack of the Cybermen
Alien Coins
from Planet of Fire
Gallifreyan Staser Pistol
from Day of the Doctor/Hell Bent
Dalek Projenitor
from Victory of the Daleks
Home Box
from Time of the Angels
Siege Mode TARDIS
from Flatline
Full-Sized K-9
First Doctor Sonic
from Lego Dimensions (video game)
Full-Sized Cybermen Helmets
from The Tenth Planet,
Wheel in Space,
The Invasion,
and Earthshock
The Master's TCE
from Spyfall
War Master's
Laser Screwdriver

from Rage of the Timelords (audio)
The Rani & Tetrap Bracelets
from Mark of the Rani
and Time and the Rani
Cybermat
from Wheel in Space
The Master's TCE
from Colony In Space
and Claws of Axos
Neural Relay
from Hell Bent
Adipose Pill Pendant
from Partners in Crime
Sonic Screwdriver
from Dark Eyes (audio)
7th Doctor Signal Detector
from Ghostlight and
Dimensions in Time
Movellan Virus Capsules
from Ressurection of the Daleks
TARDIS Toolkit
from Earthshock
7th Doctor Spoons
from Time and the Rani
Division Badge
from Survivors of the Flux
and The Vanquishers
13th Doctor Fob Watch
from Survivors of the Flux
and The Vanquishers
Key to Time
from The Armageddon Factor





5.5" Scale REMIX Figures:
Figures and playsets in scale with the existing 5.5" Character Options range of figures that I have personally remixed to be fully articulated and/or add improvements.

REMIX001 - Battle Damage Emperor Dalek
Original design by Edward Felix, Remixed by Troy Ryan Wood
Version 3 - Updated 1/16/2021

Final: https://drive.google.com/file/d/1_swhbjRDHv3TzoksyxxtzYThxmMEVuMo

Notes:
This was my first remix, and mainly a superficial one. The outside is almost entirely Edward Felix's original design, I just pimped it out by adding a movable eyestalk, alignment pegs, Flashing LED string light support, the large triangular plinth and two removable front panels and an exposed central core that will let you transform the figure into the burnt out "dead" version with exposed wiring as seen in the climactic battle at the end of episode 7. (Even though this episode is missing and all we have are some behind-the-scenes videos shot with a handheld camera)



Print Recommendations: This figure has multiple alternate file options depending on what features you want to add to your Emperor. Note that while there *is* a SLA resin version, the Emperor is far too big to print on a regular-sized resin printer like the Anycubic Photon or Elegoo Mars. You'd need to print the skirt on a regular filament printer or one of the expensive large scale resin printers if you want it to come out successfully.
For PLA filament printing, I recommend printing at 80 to 100% infill if you're planning on adding LEDs so it doesn't glow through the plastic too badly. You can drop down to a lower infill amount for most pieces if you won't be using lights. The eyestalk should be printed at 100% fill for maximum durability. (You may want to print a spare just incase the first one snaps.)

All versions of the figure use the same Head and Dome parts. There are two versions of the Eyestalk depending on whether you are printing in PLA or SLA resin (on a resin printer you have the option of inserting a tiny LED into the eye itself!).

There are two versions of the triangular Corner Plinth (which is entirely optional.)
There's a Solid version that can only be printed of very large printers, and a Split version, that is split into three parts, if it makes it easier to print.

Battle Damage Skirt (No Hemis) - Use this version if you are printing the Battle Damage version on a PLA filament printer.
You will need to print the Left Damage Panel No Hemis, Right Damage Panel No Hemis, Black Hemis and Black Button Hemi files to go with this version. The hemispheres (or dalek bumps) are separate so you can print them flat without overhangs. You only need to print the Black Button Internal for LED file if you intend to mount Flashing LED string lights (this should be the type that has a button.) If you do not, you still need to print the separate Black Button Hemi to cover the hole. It is recommended that you print the Internal Battle Damage Core with this version as it provides support for hoses and wires, but is not essential if you want to completely build the inside from scratch.


Battle Damage Skirt (With Hemis) - Use this version if you are printing the Battle Damage version on a large sized resin printer or are using one of those fancy dual-extruder filament printers that lets you print disolvable supports so you don't have to worry about ugly overhangs.
You will need to print the Left Damage Panel With Hemis, Right Damage Panel With Hemis, and the Black Button Hemi files to go with this version. You only need to print the Black Button Internal for LED file if you intend to mount Flashing LED string lights (this should be the type that has a button.) If you do not, you still need to print the separate Black Button Hemi to cover the hole. It is recommended that you print the Internal Battle Damage Core with this version as it provides support for hoses and wires, but is not essential if you want to completely build the inside from scratch.

Solid Skirt (No Hemis) - Use this version of the skirt if you want a regular undamaged Emperor. You do not need to print the Internal Battle Damage Core or any of the Damage Panels. You will still need to print and glue on the Black Hemis and Black Button Hemi for this version, even if you do not intend to mount LED lights.

Color Recommendations: The exterior is pretty simple since we have good reference photos. The upper dome and upper two chest hemispheres should be a yellowed cream color, approximately the same color as unpainted fiberglass resin. (Fun fact... the head of the Emperor Dalek is actually a Chumbley recycled from Galaxy 4!)
The majority of the head and body is light grey (Testors "Light Ghost Grey" seems to be a pretty close match) however, the interior of the lights encircling the head are white, and the slats between the "crown" parts of the head are painted the same black as the body hemispheres, "candy apple" part of the eyestalk, collar, and "bib" behind the upper two hemispheres. The end of the eyestalk is grey with a white iris.
If you intend to hook hoses to the outside of your model, you'll want to look for some 4mm OD/2mm ID white silicon tubing. If you want to be extra accurate, paint or sharpie the last mm or so of the tube black where it connects to the pegs on the body.
The plinth is dark blue, with silver trim around the edges.

The interior is another matter. I recommend painting the Internal battle damage core and most of the Emperor Dalek interior black to start with. The mutant core should be green. The curled "telephone" hoses are easiest to replicate by getting a few different thicknesses of wire, and just wrapping them around different cylindrical objects like pencils, painpaintbrush handles, and the 1.5mm rod used for securing the eyestalk. It looks like they were a wide variety of colors, so just use whatever's handy. You may want to give the core a light spraydown with dilluted black airbrush paint before final assembly to blacken and stain everything a bit so that it looks like it's been on fire.




Assembly Instructions: If you are using the optional LED string lights, the first thing you need to do before assembling anything else is push the Black Button Internal for LED (the little peg part) through the square hole on the inside of the emperor so the round end sticks out through the back. This is what you'll be gluing the Black Button Hemi to eventually, but once you've got the button through the hole, hold the skirt so the button is lying flat, and you can slide your LED string light into position from the slot near the neck section, you'll need to slide it down so that the LED string comes up through the same hole on the left side (which has a slight circular hole cut into it) Everything should line up in such a way that the peg you inserted earlier lines up with the button on the LED battery pack, and pushing it from the outside will turn the lights on and off.

If you want to be able to change the batteries later, I recommend that you do not glue the battery pack in place, or only use hot glue that is easy to remove later.

The rest of assembly is easy. The head and dome only go on one way. (If you want to leave the battery pack accessible You should either not glue the head, or glue it with hot glue or something you can pry loose later.

If you're using LEDs, Insert the LED string lights into the light holes around the edge of the crown. These will need to be sealed in place. You can use crazy glue, but I prefer using UV craft resin. The lights will alternately blink when you turn them on with the button. This is screen accurate from what we can tell from a few surviving behind the scenes clips.

If you printed in resin and intend to mount a LED in the eyestalk, you will need to clip off the very end of the LED string (leave at least a couple of centimeters of wire after the next light) then burn the ends where you cut the wire with a lighter. There's an incredibly thin insulation coating you need to strip away. Once that's done, insert the lone LED into the eyestalk hole and feed the wire through the tiny hole into the head. Use electrical tape to very carefully reattach the wires. This is easiest done with the lights turned on, so you can make sure you're getting a clean contact. The voltage on these lights is so low, you don't have to worry about getting a shock.

Once you've got LEDs in place (if you're using them) mount the eyestalk in place with a length of 1.5mm wide brass rod trimmed to the right length, or failing that, a toothpick or bit of coat hanger.

The internal Battle Damage Core has several holes where you can mount springs, wires, or bits of extra tubing. I originally intended to use springs for my design, but found that simply wrapping lenths of different gauge wire around the 1.5mm brass rod, an old screwdriver, and a few different sizes of paintbrush handle gave me a nice assortment of curly tubes to add to the center. I recommend gluing the Battle Damage Core in place to the back wall once you have everything set up the way you want it. there should be no reason to remove it from the figure once it's in place since it doesn't interfere with the LED pack.





REMIX002 - Kronos (Chronovore)
Original design by James Lee, Remixed by Troy Ryan Wood
Version 2 - Updated 11/16/2020

Final: https://drive.google.com/file/d/1n1HSEg9pMhIpdJ7vM7rc62N9hprBneo2

Notes:
This is the first of many amazing figures designed by James Lee that I'll be adding articulation and minor tweaks/detail upgrades to.
He's cranking these things out 6x faster than I can work on them, so check out all his other incredible creations and know I'll try to get to as many of them as I can, but I still have my own figures to work on as well!

Print Recommendations: The files used to print this figure are the same, regardless of whether you are printing in
PLA (filament) or SLA (Resin) unless specifically noted. This figure should be printable in PLA (James original was) but the shoulder pads are very thin and may require additional support. I have included two alternate versions of the wings; a solid version for PLA and a SLA version that has a separation between the front and back edges of the wings.

Color Recommendations: This is one figure you can get away with not painting at all if you printed him in white to begin with.
If you want to add an extra bit of detail, the eye screens in the mask should be a dirty grey, and there's some slight discoloration around the edges of the crest. Otherwise, he's all white.


Assembly Instructions: Begin by attaching the wings to the shoulder pivots with 1.5mm wide brass rod trimmed to just a couple of mm shorter than the depth of the hole. I prefer the brass rods for my design because they're incredibly sturdy while still easy to cut, but you can always use a toothpick or bit of coat hanger if you want.

Once the rod is all the way through the shoulder pivot, seal the open end with UV craft resin, craft putty, or crazy glue gel. Then do the same to attach the legs to the thighs (make sure you have the feet pointing the correct direction before you seal it in place! The legs should bend backwards but not forwards)

Next, take the hip sheaths (the small half cylinders) and clamshell them around the hip joints on the crotch. they should spin freely. If not, you may need to file them a bit. Usually, you don't need to glue the hip sheaths together themselves, just put some crazy glue into the thighs, and slide the hip sheaths into place.
Stick the leg assembly up through the central hole in the skirt, and clamshell the torso around the other end, as well as the two wings and the head. Make sure all the pieces fit together and move correctly before you crazy-glue the torso shut. If the hips are loose, you may need to glue the top part of the skirt to the underside of the torso.
Finally, add the shoulder pads, and you have an fully assembled Chronovore.


REMIX003 - The Meddling Monk and TARDIS
Original Monk head sculpt by David Turner, Monk's TARDIS by Jeffrey Fink, Remixed by Troy Ryan Wood
Version 2 - Updated 2/12/2022

Final: https://drive.google.com/file/d/1rSz_tEKqhWtzPFLzFtQ0q_NKMvmhwC2Q/

Notes:
This figure came about because David shared his amazing 1:6 scale Peter Butterworth head sculpt with the group, and I already had a fairly screen accurate monk's robed sourced that I hadn't done anything with. Jeffrey also kindly provided the Monk's TARDIS to complete the set. Special thanks to the "Scan the World" project, and Saint Anthony of Pauda... whoever you were, for providing the original robe.
You can find David's original 1:6 scale head, as well as several of his other designs below in the "Other Scale" section.


Print Recommendations: The files used to print this figure are the same, regardless of whether you are printing in
PLA (filament) or SLA (Resin). The Monk should be printable in PLA, but SLA resin is highly recommended, at least for the head(s) to maximize facial detail. When SLA printing, always angle the head approximately 45° so that the face is pointing up away from the build plate. I recommend using a flexible resin like 3DMaterials SuperFlex or SirayaTech Tenacious as an additive, at least for the hands and accessories to prevent accidental snapping.

The Monk's TARDIS is primarily designed for PLA filament printing, as is too large to fit on most entry-level resin printers, even if you rotate the design. If you do resin print, you will likely have to plane cut the Top, Middle, and Base into two halves so that they will fit in your build area. Make certain that you clean out the hinge holes thoroughly before you cure the doors, otherwise they may dry solid and you will have to attempt to drill them out.

This zip files includes three subfolders for The Meddling Monk, The Monk's TARDIS, and Optional Accessories. Optional accessories are not necessary to print the main figure but are available if you want to print:

  • Alternate quick-swap Monk's head with sunglasses as seen in The Daleks' Master Plan.
  • Alternate quick-swap 1st Doctor head to create the disguised Doctor from Episode 4, or the Abbot of Amboise from The Massacre. (Since no telesnaps exist for that story, and we have no idea what the 1st Doctor's doppelgänger costume actually looked like)
  • The stick used as a pretend rifle by the 1st Doctor to threaten the Monk.
  • A space helmet for a cow
  • and a pair of sunglasses (separate) for the Monk to wear. Note this is very small and very fragile and you will need to mix in at least 50% flexible resin as an additive if you are printing out of SLA resin so that it will bend rather than break.

The Monk's TARDIS has an optional printable insert if you want to add a sticker or cardstock to the back interior wall showing the shrunken console room interior. This should ideally be printed at 600 DPI (standard DPI for laser printers), and measures 147mm wide by 93mm tall (the same dimensions as the back wall).

Color Recommendations: Before painting, make sure you test assemble all parts without glue to make sure they fit and move correctly, and any parts that are too tight get sanded down.

We do not have color reference photos for the monk's costume, but the robe appears to be an extremely dark brown, and his skullcap looks to be roughly the same color. His belt would have a been a light sisal-colored tan. While we don't get a good look at his sandals they were likely leather and a similar color to his robe. His feet and legs would have been bare.
Peter Butterworth's hair looks much darker during television appearances in the 1970's, but he often sported a much lighter chestnut color during the 1960's, as can be seen in the Carry On films. Given that his hair appears so much lighter than the skull cap and hood durring The Time Meddler, I believe his hair was probably fairly close to the color shown in the example photos below.

Likewise, we don't have color references for the Monk's TARDIS, but it should be a light grey stone color. The center of the rectangular panels tend to be slightly lighter than the rest of the altar, with the cracks and corners are darker. The inside should be painted flat black, except for the rear wall if you are going to be printing the shrunken TARDIS interior sticker.


Assembly Instructions: After painting, begin by assembling the elbow and leg joints using 1.5mm wide brass rod trimmed to just a couple of mm shorter than the depth of the hole. I prefer the brass rods for my design because they're incredibly sturdy while still easy to cut, but you can always use a toothpick or bit of coat hanger if you want.

Once the rod is all the way through the elbow pivot, seal the open end with UV craft resin, craft putty, or crazy glue gel. You can do the same with the legs, but this is not strictly necessary, as once you insert them up inside the robe, they will be locked in place and cannot fall out.

Next, flip the lower half of the robe upside down and insert the legs/crotch so that the pegs slot into the peg holes. When assembled correctly, you should just barely be able to see his toes past the bottom of the robe. Note that if you printed the skirt with internal supportsyou may need to sand or file down the inside to make sure that the crotch can travel all the way down and sit flush without getting caught on anything.

Next, pop the ball joints of the arms into the shoulder holes of the upper hood. It may be a tight fit, and if they won't pop in on the first try, you may need to sand down either the ball joint ot the edges of the shoulder holes.

Finally, glue the front and back chest around the T plug of the lower robe like a clam shell so that the waist moves freely inside. Once this is dry. glue the upper torso to the lower, making sure that the arms still move freely in their sockets.

For the Monk's TARDIS, first stick the shrunken TARDIS interior image to the inner back wall of the model if you plan on using one. Make sure you know which direction is up. (The tapered corners should be down at the bottom)

Next, glue the center section down to the base, then insert the two doors, and drop 1.5mm wide brass rods down from above to act as internal hinges, trimming the rods to be 1mm shorter than the upper edge of the hole. (The rods need to go all the way through into the base. Make sure you test both doors to make sure the rod has gone all the way down locking it in place, and both doors swing freely without coming loose.

Then glue down the top of the model, sealing the internal hinges from both ends.


REMIX004 - Key To Time and Tracer
Original design by Dan Liwszyc, Remixed by Troy Ryan Wood
Version 1 - Updated 2/13/2022

Final: https://drive.google.com/file/d/1NeMleGUeU0GqZFJ0z7UdTbmD0dFj0J4j

Notes:
A quick and easy remix of Dan's 1:1 scale version you can find down in the props section, with the addition of a tracer to complete the set.

Print Recommendations: You're going to want to print the key out of clear SLA resin if you can. You can try printing out of transparent PLA or PETG, but it will not be perfectly clear like the original prop.
If you don't have a resin printer, you can always try printing the pieces out of normal PLA, then pressing them down into clay or plaster to create an inverse mold (make sure the widest flat side is on the top) and then filling the hole with clear epoxy craft resin.

There are two versions of the tracer: Tracer for SLA and Tracer For Flat PLA Printing.
The SLA version has buttons on all four sides of the handle, but because the round section is only 2mm wide, it will likely snap if it is not printed out of a special flexible resin like 3DMaterials SuperFlex or SirayaTech Tenacious.
The flat version is designed to be printed flat on the build plate using PLA or PETG. This only has buttons on 3 sides and the tracer rod will need to be rounded off on the bottom edge.

This set also includes an optional extra Segment 6 stand-in, which is the fabricated version of the 6th segment as seen in The Armageddon Factor with a bumpier texture suspiciously like styrofoam.

Color Recommendations: There were multiple versions of the Key To Time featured during season 16, including the original cast lucite segments used during the first five stories, and a hollow version used to replicate the assembled cube for the final story. The cube segments should be clear resin color.

The tracer has a clear rod with a red insert that sticks out about 3/5 of the way up from the handle. This was to small to replicate accurately at CO scale, so you might have to settle for painting this part of the tracer pink. The handle of the tracer is a light grey, similar to the color of the TARDIS walls, and both ends are white. The button colors alternate in the following pattern:

Base: Yellow/Red/Yellow/Red
Middle: Orange/White/Orange/White
Upper: Red/Yellow/Red/Yellow (the opposite of the base row)

The stand-in segment piece is a whitish silver, the color of a painted piece of styrofoam.

Assembly: There is no assembly necessary for this figure. But if you are having trouble figuring out how the 6 pieces of the Key to Time slot together....



5.5" Scale Figures:
Figures, play sets, and set pieces in scale with the existing 5.5" Character Options toy range.
These figures have been designed by other artists and may or may not be articulated. Expect some of these to eventually make it to the REMIX section above.

Classic 60's TARDIS Interior Play Set
by Chris Jones


Download:

Notes:
An impressively complete build here, even going so far as to include the various antique chairs, armillary sphere, cathedral clock, and food machine seen during the first season. Everything has been test printed by the author and verified functional. You can also download the Astral Map and Time Space Visualizer a little further below.

Secondary Console Room TARDIS Console from Season 14
by Jeffrey Fink


Download:
Console:
https://www.dropbox.com/sh/rcc8w8nttirc8ra/AAB1-BU0WgDxoaSK43e02Em-a?dl=0
Console Base: https://www.dropbox.com/sh/g4xh8kibej67kxw/AADlvUG6Q-0MpxYOmakrKSyka?dl=0

Notes: Another glorious design by Jeffrey Fink who also created the 8th Doctor Console room set my own version was based around. The writing surface doors open, the drawers slide out, even the tiny little metal rams heads are exquisitely detailed. You're going to want to have this resin printed, or head over to Shapeways and have the metal rails and rams heads custom printed in actual brass or bronze!



Rani's TARDIS from Mark of the Rani
by Jeffrey Fink


Download: https://www.dropbox.com/sh/g484dbc2ehwm5nh/AACSpMShbMROu6XC0-SqnsC_a?dl=0

Notes: Because of the size and wall thicknesses, the walls are designed to be glued along the edges. The roof frame is designed to allow the sides to slot into it, but there are no slots on the base. The peg holes for the doors will need to be cleaned after printing.

The two front panels have a slot for a 2.4mm rod to be inserted into them. There is enough space on the back of the panels to allow for lighting if you wish. The base is opened on the under side and should have enough room for a battery pack.

Zero Room Playset from Castrovalva
by Smappy


Download: https://www.tinkercad.com/things/aGFAvzuc7e0-zero-room

Notes: Currently untested. See Smappy's notes on TinkerCAD for assembly/additional parts details.

"Hudolin" 8th Doctor TV Movie TARDIS
by Smappy


Download: https://drive.google.com/open?id=1UdCQKYHS6SzrxczcMPxsSmVR2ItCcqj5

Notes: Verified working. See instructions in Google Drive folder for reference images and stickers to print.

"Brachaki" 1st Doctor TARDIS from Seasons 1-3
by Smappy


Download: https://drive.google.com/drive/folders/1KplLxbPCgMJWRV1fFkGPXTHPJMtDG7TZ

Notes: Verified working my multiple users, but back wall may have an error.

Emperor Dalek from TV 21 Comics
by Louis D'Angelo


Download:
https://drive.google.com/drive/folders/1VN1mwjKm3bpnpF2ZYDCFPC3Sq2WGZGrh

Notes: Includes alternate version of the upper dome for circular lights rather than a straight line.

Astral Map from The Web Planet
by Chris Jones

Download: https://www.thingiverse.com/thing:3687277
Notes: This design features a slide open panel and is compatible with a LED Light brick. Watch it in action below!



Time-Space Visualizer from The Chase
by Chris Jones


Download: https://www.thingiverse.com/thing:3591984
Notes: I eventually plan on releasing a remix of this design that will allow you to insert slided or a small LCD keychain into the screen area.

Tomb of the Cybermen Play Set
by Chris Jones


Download: https://www.thingiverse.com/thing:4325601


Dalek City Play Set
by Chris Jones


Download: https://www.thingiverse.com/thing:4556056
Notes:
This is a truly impressive modular design (with functional lift shaft) based loosely on the version seen during the 1963 story 'The Dead Planet'

The Whomobile from Planet of the Spiders
by Chris Jones


Download: https://www.thingiverse.com/thing:4681236
Notes: This design is jumping to the top of my remix list for 2021. Chris has come up with an amazing design here that even includes a functional steering column.


Absorbaloff from Love and Monsters
by James Lee


Download: https://drive.google.com/file/d/1_KdmCiB5b2XH0dCnQzUI88-hdd2H_dpc
Notes: The first of many figures designed by the prolific and talented James Lee.
This figure even comes with an optional cane and pavement-stone face accessories!
Note that the mesh has fine detail than a standard resolution resin printer simply can't reproduce. The arms and legs are attached via a simple universal peg design which means you should have no difficulty printing this figure in either filament or resin, but resin will give you significantly improved surface detail.



Chameleon from The Faceless Ones (animated)
by James Lee


Download: https://drive.google.com/file/d/1wlXDc2hEhXzOev5rjvYadeQgJ2FQK13Z
Notes: Not to be confused with Kameleon, the 5th Doctor's robotic companion and unfortunate stooge of The Master, these are the enemy of the 2nd Doctor who look like they were attacked by silly string.
As with most of James' designs, the mesh has more detail than a standard resolution resin printer can reproduce. This is another universal peg design figures that should print just fine in either filament or resin, though as always, resin will give you greatly improved surface detail.

Draconian from Frontier In Space
by James Lee


Download: https://drive.google.com/file/d/1-Z_HNqqnR343ocVznMVPnzckEkQwp3a5
Notes: As with most of James' designs, the mesh has more detail than a standard resolution resin printer can reproduce. This is another universal peg design figures that will print just fine in either filament or resin, though resin is definitely the way to go if you want to see all those little scaly bumps and beard whiskers when it finishes printing.

Cyber Warrior from Ascension of the Cybermen
by James Lee


Download: https://drive.google.com/file/d/1ZeId8XjZDGqrv1sNSswUTK6RbqoA-qZ4
Notes: This figure uses a ball and socket design for the head that will not work without modification on resin printers (you'll need to sand it down after printing so that it basically becaomes another peg.) Due to the angular nature of this design, it prints fairly well on a regular filament printer, though resin will give you improved surface detail, especially on the overhangs.

Cyber Master from The Timeless Children
by James Lee


Download: https://drive.google.com/file/d/1q8vzNDUhWWAvgjLGbPujYnxQHe2FS4c7
Notes: This figure uses a ball and socket design for the head that will not work without modification on resin printers (you'll need to sand it down after printing so that it basically becaomes another peg.) Due to the angular nature of this design, it prints surprisingly well on a regular filament printer, but resin will give you improved surface details, especially on the collar and robes.
Dalek Trooper from Resurrection of the Daleks
by James Lee


Download: https://drive.google.com/file/d/1vDlJfxxADU3kaeoclqpxIpjtqVURUwz1
Notes: This is another peg design figures that should print just fine in either filament or resin, though as always, resin will give you improved surface detail.

The Destroyer and Knight Commander from Battlefield
by James Lee


The Destroyer Download: https://drive.google.com/file/d/1CRxaWCTRyA6ES7tlpy__kMF_Lp8o8vby
Knight Commander Add-on: https://drive.google.com/file/d/1-jsoHlnDlsgmq64TIF2HrEsHZgRktIp7

Notes: This is a two-fer, with the main armor of the body doubling for both versions. To print the Knight Commander, you'll need to download the Destroyer model and just change out the appropriate parts.
This is another peg design figures that should print just fine in either filament or resin, though as The Destroyer is arguably the single most detailed monster of the classic series, you'll really need a resin printer to do it true justice.

Ice Lord from Monster of Peladon
by James Lee


Download: https://drive.google.com/file/d/1njbcNlLX_r4mzTQEzYI58gEmEsUBKWrQ
Notes: This is another peg design figure that should print just fine in either filament or resin, though as always, resin will give you improved surface detail.

Kronos from The Time Monster
by James Lee


Download: https://drive.google.com/file/d/1vUl2O5N6cFZglGjxkcQDqXYzOw6LXTEL
Notes: This figure has been remixed by Troy Wood to have improved articulation and surface detail. However, you can always download the original version if you want.

"Nightmare" Cyberman from Nightmare in Silver
by James Lee


Download: https://drive.google.com/file/d/1lqsc7Qxkm4EmyIOQ42rAYumkSv6-liec
Notes: This figure uses a ball and socket design for the head that will not work without modification on resin printers (you'll need to sand it down after printing so that it basically becaomes another peg.) Due to the angular nature of this design, it prints fairly well on a regular filament printer, though resin will give you improved surface detail, especially on the overhangs.

"Wheel" Cyberman from Wheel in Space
by James Lee


Download: https://drive.google.com/file/d/1jiAtPk9rvBMEP1IEb97Ni6Kha_z-nihI
Notes: As with most of James' designs, the mesh has more detail than a standard resolution resin printer can reproduce. This is another universal peg design figure that should print fine in filament or resin, but you may lose some of the smaller surface details and hoses if printing in regular filament.

Peter Cushing "Dr. Who" from the 60's Dalek movies
by James Lee


Download: https://drive.google.com/file/d/1yEkNxiulWeEfYLER5XqWQEgBTBhRbwCG
Notes: The surface detail on this mesh is astonishing detailed and will look absolutely gorgeous if you resin print it. But it still prints fairly well in regular filament, and uses the standard peg design for the arms and legs.

Sontaran Steg from Shakedown: Return of the Sontarans (spin-off)
by James Lee


Download: https://drive.google.com/file/d/12DdcMgkVkz9IfriwiEym9a6rfV9GVA-z
Notes: The new Sontaran design featured in the Shakedown direct to video movie. Due to the angular nature of this design, it prints fairly well on a regular filament printer, though resin will give you improved surface detail, especially on the overhangs. It uses the standard peg design for the arms and legs and also comes with an optional Two Doctors style gun accessory (Though if you want a slightly more screen accurate version, you can download one here.)

The Lone Cyberman from The Haunting of Villa Diodati
by James Lee


Download: https://drive.google.com/drive/folders/1RWErJ5S2LQqLCdvbfDQEhYRauP41TRSy
Notes: The angular nature of the cyberman means that this one prints surprisingly well with regular filament. The arms and legs are attached via his universal peg design which means you should have no difficulty printing this figure in either filament or resin, but resin will give you significantly improved surface detail.

Blackpool Exhibition Entrance TARDIS (exhibit)
by Grant Holdsworth


Download: https://www.thingiverse.com/thing:3815400
Drainpipe add-on: https://www.thingiverse.com/thing:3816272
Notes: Grant really went a different direction with his design, faithfully recreating the entrance to the 1982 Doctor Who Exhibition at Blackpool, even down to the drainpipe on the back.
He's also working on a version of the bright red 1960's Dalek ride toy which you can check out some photos of on his instagram.

Golden Emperor Dalek from Timelord Victorious (animated)
by CaptainJimiPie


Download: https://www.thingiverse.com/thing:4627305
Notes: Jimi is primarily known for his customization work and youtube videos, but built this model as a stand-alone kit based off the Golden Emperor Dalek featured in the Timelord Victorious Daleks! animated series. While I believe he printed the example below in regular filament, looking at the design, there should be no reason why it wouldn't print just as well in resin. You can check out his video for this particular creation here.


Mr. Smith from The Sarah Jane Adventures
by Daniele Roccati


Download: https://www.thingiverse.com/thing:4555073
Notes: A very cool replica of Sarah Jane Smith's other faithful electronic companion.

Proposed Season 27 TARDIS Console Room
by Michael Thresher


Download: https://www.thingiverse.com/thing:4561299
Notes: Based on Mike Tucker's concept design drawings and model for a proposed Season 27 console room redesign (which was briefly used as a backdrop by Sylvester McCoy's for some 35th anniversary wrap-arounds on BBC Choice.) This design includes the console, but not the rotor, and requires a handful of clear parts for completion.

TT Capsule (TARDIS without Chameleon Circuit)
by Stephen Miller


Download: https://www.thingiverse.com/thing:2515661
Notes: Based on the slimmer version stolen by the 12th Doctor in Hell Bent. The Type 40 stolen by the 1st Doctor and Susan during The Name of the Doctor was significantly wider and taller, so presumably this version is a more recent model.

The Rani's TARDIS Console from Mark of the Rani
by Jeffrey Fink


Download: https://www.dropbox.com/sh/r676pebm58ji7fo/AAAYXNi15TD2ZFOpOyNAufoAa
Notes: A gorgeous reproduction of The Rani's console room (embryonic dinosaurs not included, though you can find some here.) Jeffrey has also kindly provided the following painting/assembly guide:







Dalek Transmat from Evil of the Daleks
by Chris Jones


Download: https://www.thingiverse.com/thing:4730726
Notes: Although not referred to by name, this "mirror cabinet" teleportation device employed by the Daleks during Evil of the Daleks is the first recorded use of a Transmat in classic Doctor Who. If you're looking for the more recent Dalek Transmat used in Remembrance of the Daleks, you can find it here.

The Moment (Button) from Day of the Doctor
by Rob Ackers


Download: https://drive.google.com/file/d/1cYP30reIdW2Q9vXjUq3MVIPgk-ygQqqh
Notes: This is the button extension for The Moment, designed to fit over the top of your existing Moment accesory from the War Doctor figure set.

Kasaavin from Spyfall
by James Lee


Download: https://drive.google.com/file/d/1aZSYicHjgpZhGHupXQCPe_CtFlBSTmQx
Notes: AKA the vaguely starfish-headed aliens made of light with the ill-defined plans to turn humanity into hard drives from the two-part opening story to season 12.
The General from Day of the Doctor and Hell Bent
by Rob Ackers, James Lee, and Troy Ryan Wood


Download:
Rob Ackers/James Lee Body:
https://drive.google.com/file/d/1GjG9Q4qnvddLlSWUhe25S_qZ0Ndub-50
Alternate Troy Ryan Wood Head: https://drive.google.com/file/d/1tDpnDtybgA-lnjy0jJpU-9kMFnmGLA9I
Notes: This is truly a collaborative effort as Rob remixed James' Cybermen and Destroyer figures to make the body for a custom designed to reuse an existing Dr. Constantine head from The Empty Child (pictured right below). Meanwhile, James remixed his remix, and I provided a slightly higher quality alternate 3D printable head to make this a full-fledged figure rather than just a custom piece.
As you can see from the photo on the left below, a lot of the fine detail on the head is lost due to filament printing. It should look a lot better in resin, but you can still use the preexisting Dr. Constantine head if you want a fairly accurate version that you don't have to worry about painting.


Baltazar from The Infinite Quest (animated)
by James Lee


Download: https://drive.google.com/file/d/1QFdSirCshg9FW-CJbPCwJoHgrzmv56w_
Notes: A fiendish space pirate from the animated 10th Doctor adventure The Infinite Quest.

Barnabus from TV Comics
by James Lee


Download: https://drive.google.com/file/d/1uqYMzRVrhhqzIvfgVP_C2dv5jt0Re5Oe/
Notes: James has resurrected possibly the most obscure Doctor Who companion yet. Barnabus was a robot butler built by the Second Doctor to do chores around the TARDIS and serve tea. He only appeared briefly in 1967, and was promptly forgotten, but does hold the dubious honor of being the "first" robot companion to join the TARDIS crew.

The Trods from TV Comics
by James Lee


Download: https://drive.google.com/file/d/1VJFDFqnuWyN_KdPORWuhLrMvRFzl7RPb/
Notes: The Trods were an attempt by TV Comic to find a cheap alternative to the Daleks who could pursue The Doctor and his grandchildren John and Gillian throughout time and space, but in an affordeble, royalty-free way. Like the Daleks, they ran on static electricity, had their own time machine, and the second Doctor even hid inside the hollowed-out shell one while trapped inside a "Time Museum." Sounds a bit familiar.



Emoeror Dalek Throne Room Play Set from Evil of the Daleks
by James Lee


Download: https://drive.google.com/file/d/1jWPxtVRAGMi29mR-BDJR5uvlMmBLlXuK
Notes: A flat panel version of the backdrop to the Emperor Dalek's throne room. This includes a version of the blue wedge platform that's slightly narrower than the version included with my own Battle Damage Emperor Dalek Remix Figure.

The Slyther from The Dalek Invasion of Earth
by James Lee


Download: https://drive.google.com/file/d/15vPSos2NrqQNhAypBJAOCOerZDchHDVf/
Notes: Only glimpsed on camera for a few seconds before plummeting to it's death at the beginning of episode 5 of Dalek Invasion of Earth, this "pet" of the Supreme Controller of the is actually the second version of the infamous Slyther costume. The first verision, which looked more like a giant jellyfish was seen even more briefly during the cliffhanger to episode 4, but was deemed "not scary enough" and taken back to Shawcraft to be fitted with two goofy bulbous eyestalks and slightly beefier arms.
Needless to say, neither of these hasty additions were very much help, when it came to trying (and failing) to leap across a dangerous gorge to the mining cart where Ian was waiting to hit in the face with a rock.

The Trickster from Sarah Jane Adventures
by James Lee and Scott Richards


Download: https://drive.google.com/file/d/13TZdvGQ6AudCdwfDApynY5uX9M8V9eFV/
Notes: A complete figure of the Sarah Jane baddie built by James Lee, incorporating the excellent head sculpt by Scott Richards.
If you're interested in just the head (for use with a Winder body or other cloaked figure) you can find it down below in the customs section.



Trantis from Mission to the Unknown
by James Lee


Download: https://drive.google.com/file/d/1YrmCmGqk-WAaQjgsBOS-sxenXakSRJ69
Notes: One of the evil Galactic Council who conspires with the Daleks in Mission to the Unknown and The Dalek's Master Plan. This is the version seen in the single-episode Mission to the Unknown prequel which had several leech-like face protuberances. The version from Master Plan was played by an entirely different actor with a similar haircut, but a slightly different costume, no face leeches, and sharpened teeth.

The Kandyman from The Happiness Patrol
by Rob Ackers


Download: https://drive.google.com/file/d/1_qJnsfCbwJrewgTxlLvm0lYdjxLeL3PX
Notes: An incredible addition by Rob Ackers. A lot of people have been requesting this figure for quite some time, and I'm simultaneouosly awestruck and jealous that somebody else beat me to it (and made it fully articulated to boot!)

Dinosaur Stun Gun from Invasion of the Dinosaurs
by Spyduck and Troy Wood

Download: https://drive.google.com/file/d/1o_ngL1eYNfvM5GnmgQ3aip26T5LT9mFM

Notes: Modified from the original version created by Spyduck. This version has been resized for 3D printing (I have verified it will print in resin, filament printing is dubious) with a few modification including adding the groove to the top of the gun, the side panel, and battery pack.

13th Doctor Console Room
by Otto Zegers

Console: https://drive.google.com/file/d/1ctDrcgb2Q924kYKut1yhjRed9X019onM
Time Rotor:
https://drive.google.com/file/d/1oW0Rn-GC5yi33uUjhg5Ga3SUczZs5Ump

Notes: Console may require additional support structures while printing.

Kamelion from The King's Demons and Planet of Fire
by James Lee

Download: https://drive.google.com/file/d/1EmnOW8rKblrj-HrunAGNJpYS63dWDGdW

The Anne Droid from Bad Wolf and The Parting of the Ways
by Rob Ackers

Download: https://drive.google.com/file/d/1z1ptVzVDtms1pHeRIZHnWxtvG98cuOMl

Trin-E and Zu-Zanna from Bad Wolf and The Parting of the Ways
by Rob Ackers

Download: https://drive.google.com/file/d/1IVa9E4gkoKhjwIScGRIGgtJqZVespnpR

Dalek Control Panels from Mission to the Unknown
by Chris Jones

Download: https://www.thingiverse.com/thing:4834403

Sontaran Scout Ship from The Time Warrior
by Chris Jones

Download: https://www.thingiverse.com/thing:4834403

Chris Jones, who was an extremely active member of our 3D printing group and responsible for creating many of our project's most popular designs, sadly passed away in late 2021.
His final work was the creation of a deluxe Sontaran Scout Ship based on the original design from The Time Warrior. Unlike the rotocast Character Options toy which contained a false front recess behind the door, Chris' version is completely hollow inside and contains the entire interior workings, including a functional chair and control console. Truly, a magnificent parting gift from a talented model maker.






Season 13 Sontaran from War of the Sontarans
by James Lee

Download: https://drive.google.com/file/d/1jSX5yDAHMh_Z_TEQNkhSDJYlZG_lIuNu

As usual, James is so far ahead of the curve, he's hard at work creating figures even before the episode has finished airing. This new series Sontaran also comes with a rifle accessory.

Spiridon Temple Entrance from Planet of the Daleks
by Jim Sangster

Download: https://drive.google.com/drive/folders/1W35JZislQaQukXAmU3-hDpzo9n8CpIy0

Jim created this nice diorama kit of the Spiridon temple entrance from Planet of the Daleks. It is designed to be printed flat of a standard filament printer. Due to the large size, it probably won't fit on most resin printers.

Snowman from The Snowmen
by Rob Ackers

Download: https://drive.google.com/file/d/1BLDYO7a-7zsbsy1QlvypSVwzaXsqBWY6

Comes in both a hollow and solid variant.

"The Flood" Cyberman and Cybercontroller from The Flood (comic)
by Calum Dunn

Download: https://drive.google.com/drive/folders/1qGX4bO30GDRy8d1cvFGPoAGs_sUASCig

Calum has recreated an excellend likeness of the futuristic Cybermen seen in the final 8th Doctor comic strip "The Flood." The figure comes with alternate head and torso pieces for making the Cybercontroller version seen in the same strip.

Lost Warriors Cyberman from Lost Warriors (audio)
by Rob Ackers

Download: https://drive.google.com/file/d/1RXfycSdCpDBFmj84aJkZGQ2Ny4gy1JCN

As seen on the cover of the Big Finish 9th Doctor audio adventure Lost Warriors.

Malpha from The Daleks' Master Plan
by James Lee and Rob Ackers

Download: https://drive.google.com/file/d/1P1LmwRKeS2hr62gtHl9a4qk7p8uKtuEe

Sculpted by James Lee and articulated by Rob Ackers. This figures uses snap-together ball joints which will only work in PLA filament. You might still get it to work in SLA resin, but you'll have to clamshell the body around the ball joints.

Warrior Sea Devil from Warriors of the Deep
by James Lee and Aaron J Climas

Download: https://www.dropbox.com/sh/r0uo2ogj0cj5l97/AAAiG8dzaITlU7ThwSwDbgVHa

Original scuplt by James Lee and remixed by Aaron J Climas. This figures uses snap-in-place arm and foot joints which will only work in PLA filament, however, you can still use them in SLA if you sand them down and glue them in place. All hinged joints should function similar to my own figures where you can insert a toothpick or brass craft rod.

Make sure you print the helmet, shoulders, right hand and thighs with supports, and if you want to print a few different variants, you can mirror the skirt to the left and right, and there in an alternate taller leader head.

Cyber Console from Earthshock
by Jeffrey Fink

Download: https://www.dropbox.com/sh/1ojgv0yqf7nqf5l/AABrgcTOz8fnFcN2mlRZ7Dija

Another gorgeous creation by Jeffrey. This model is definitely designed to be printed in resin. If you're going to attempt it in filament, make sure you're using PLA+ at maximum infill with added supports. You may need to replace the emitter tubes with off-the-shelf acryllic rods if they won't print properly.


Hyperspacial Bridge from Stones of Blood
by Jeffrey Fink

Download: https://www.dropbox.com/sh/55m3l8hm6nz4u2r/AADxNOW6mWCw7PUYhCskV_3ra

A fun accessory to accompany your Ogri figure and the upcoming Cailleach. This is another one that is really designed for resin printig. If you are going to attempt it in filament, make sure you're using PLA+ at maximum infill with added supports.



5.5" Customizing Parts and Accessories:
Custom parts and accessories used for converting or enhancing existing 5.5" scale Character Options figures.
(All, 5.5" scale heads go here, but you can find more heads down in the "Other Scale" section that can be converted, with a little bit of math.)

Troy's Miscellaneous Customizing Parts
by Troy Wood

I've made a few custom fodder parts over the years, which I've included below for anyone that's interested:



The Valeyard (Head Only) To be used with Time Lord figure.


Adric (Head Only)
To be used with a Toby Zed figure or similar.


1970's Newbery TARDIS Base

1970's Newbery TARDIS Top

1980's Yardley TARDIS Base

Movie/Supreme Dalek bumper (solid) (Fits over the skirt of a Hartnell era Dalek)

Movie/Supreme Dalek bumper with holes for Lego wheels

Modern Dalek Bumper

Custom Sontaran Helmet (no eye holes)



The Trickster (head) from Sarah Jane Adventures
by Scott Richards

Download: https://drive.google.com/file/d/1JK9PFTPDWXuNkAgjwVfMqyZznK4Suz_B
Notes:
This is currently the head only, but James Lee is working on a body to go with it.


Movie Dalek Claw
by CaptainJimiPie

Download: https://www.thingiverse.com/thing:4590993
Notes:
An extendable movie dalek claw for converting your "Jungles of Mechanus" Daleks into Peter Cushing movie Daleks
.

Timelord Victorious Dalek Parts
by CaptainJimiPie

Download: https://www.thingiverse.com/thing:4627286
Notes:
Parts for converting new series Daleks
into Timelord Victorious Daleks.

New Series Dalek Parts
by Rob Ackers

Download: https://www.tinkercad.com/things/8wFicZES2wS
Notes:
Alternate/replacements parts for new series Daleks
.

Classic Series Dalek Parts and Accessories
by Rob Ackers

Download: https://www.tinkercad.com/things/f3kaPFxHRKT
Notes:
Alternate/replacements parts for new series Daleks plus a few accessories
.

'Carnival' Auton Heads from Terror of the Autons
by doctorwho.photography

Download: https://drive.google.com/file/d/1eSkYSQ-B2cF01ghztfnBINhLEPNhltSU/
Notes: James has modeled not one, but two 'Carnival' style Auton heads here!
A spare Eccleston era Editor or Primeval James Lester figure will give you a close enough approximation of the suit jackets worn by the Autons during this story.
You can check out more of his work on Instagram.

Replacement K-1 Robot Foot Part from Robot
by Chris Jones

Download: https://www.thingiverse.com/thing:4461019
Notes: This is a replacement upper foot cover for the 5.5" scale K-1 "Giant" robot figure.
This part comes off quite easily, so you often find versions of the toy on eBay missing this particular part.
While this piece is sized for the 5.5" Character Option figure,
if you rescale it to 29mm wide, it may also fit the Mego K-1 figure from the 1970's.

Kraal Android Head from The Android Invasion
by doctorwho.photography

Download: https://drive.google.com/file/d/1juQ4BR-hl-evmPOYDqLkFwoQbxn8oNPe
Notes: While you don't actually see the android duplicate U.N.I.T. soldier from this episode with his face removed, it's a great way to repurpose one of your spare U.N.I.T. or Brigadier figures you want to turn into something a little more interesting.

Sentreal Head from Mission to the Unknown
by doctorwho.photography

Download: https://drive.google.com/file/d/12MiPS0h94BnfWieEDyGeVJEKBAggBLFP
Notes: Another great head designed by James. As exampled by the photo below, you can make a "body" for this figure by simply using a toilet paper tube or anything else the same size that you've painted black.

Sontaran Rifle from The Two Doctors
by doctorwho.photography

Download:
Solid for SLA: https://drive.google.com/file/d/15-IKU6-FUR2s-WV_Drm7eL-fVH-EbNYg

Split for PLA: https://drive.google.com/file/d/1Uk-KinK6b91AQHaRfq_vGZlF3YHraBqq
Notes: It's a shame Character Options didn't provide a Sontaran Rifle to accompany their Two Doctors set, but James has helpfully provided this printed version. Note that his original model was a solid piece better suited to SLA resin printing, so I've also provided a split version that may print better on regular PLA printers.




Cyberman Head from Sword of Orion (Big Finish)
by Rob Ackers

Download: https://drive.google.com/file/d/1wcGt5cxWYVrHp6_rMJZuorb70R6s9h76
Notes: Cyberman head for customizing.

Bus Conductor Head from Greatest Show in the Galaxy
by Rob Ackers

Download: https://drive.google.com/file/d/1Sv92Dq3kdKcfn47END2LciWXkTJshvCN
Notes: For use with an existing Character Options "Suit" body. Comes with optional Ticket Machine and removable button insert. Designed for filament printing (if you want to be able to bent the ticket machine into a curved shape)

Commander Maxil Body from Arc of Infinity
by Rob Ackers and James Lee

Download: https://drive.google.com/file/d/14fdk-u0K7rgRkdKL94qKl7P_m7InVOqV
Notes: For use with an existing Character Options Colin Baker head. Designed for filament printing (if you want to be able to bent the cape into a curved shape)

Timelord Collar from Various
by Rob Ackers

Download:
With Seal of Rassilon: https://drive.google.com/file/d/1rdVIaVuFHUIG14qcB65LvQBDXY5yb9DU
WIthout Seal: https://drive.google.com/file/d/16w4ZpdAZiruRnQtQ4hxaTjGcdW-prXGY


Notes: Designed for filament printing (if you want to be able to bent the collar into a curved shape)

Rapid-Fire Dalek Gun from Eve of the Daleks
by James Lee

Download: https://drive.google.com/file/d/112jVcd6JlTJUxSf4G47Q_4u1L--PTqfs


Notes: Designed for resin printing. You might want to add some flexible resin as a strengthening agent so that it has a little bit of flex and won't snap off at the base during play. To install, simply snap off the existing Dalek gun and carefully drill a small hole in the exposed ball joint.

Kane Head from Dragonfire
by doctorwho.photography

Download:
Normal Head: https://drive.google.com/file/d/13z1PB7K4fAtjvsiFX8Lo8LmUUP0RaM8F
Melted Head: https://drive.google.com/file/d/1n_ZJkJSgUw00OZ_hLgFQSX4E40bMscE7


Notes: Designed for resin printing, but can be printed out of filament as well, if you don't mind losing most of the surface detail. If you're looking for a body to pair with either of these heads, a Grand Admiral Thrawn body (either 3D printed or taken from the Star Wars Black toy line) should be a fairly close match.


Alex Macqueen Master Head from UNIT: Dominion
by doctorwho.photography

Download: https://drive.google.com/file/d/11OPBRo6maz3GxPmEJgdMz0Ido0tCEwz3
Notes: The version of The Master from the Big Finish audio plays, this head is designed to be resin printed, but can be printed out of filament as well, if you don't mind losing some of the surface detail (luckily, he's bald). This head pairs well with an existing Character Options "Suit and Tie" figure, like Ian Chesterton or a Primeval James Lester.

Movie Dalek Customizing Parts
by Chris Jones

Download: https://www.thingiverse.com/thing:4687342
Notes:
Chris made this kit consisting of a new bumper, claw arm, and dome lights for converting an existing 60's Dalek into an Amicus Movie Dalek
.

3rd Doctor Accessory Pack
by Leighton Humphrey

Download: https://drive.google.com/file/d/15pblWnB0mZglI5GaseeBu7pFp0LQSVN1
Notes:
Leighton created a nice assortment of accessories for the 3rd Doctor, including (left to right):

  • Deep Space Probe from The Three Doctors
  • Metebelis III Crystal from Planet of the Spiders
  • Sea Devil Weapon from The Sea Devils
  • TARDIS Force Field Generator from The Three Doctors
  • Time Field Sensor from The Time Monster

Due to the small size of these parts resin printed is recommended, but the larger items will probably come out okay in PLA.

Death Zone Torch from The Five Doctors
by doctorwho.photography

Download: https://drive.google.com/file/d/1nOm01qfdr3o8UlmqBBxyMVLOSw9y5anz
Notes: An accessory or set piece designed by James Modeller. I would highly recommend printing this one in resin since the sides of the model are very thin, curved, and criss-cross.If you did want to try printing in PLA. You may have to manually slice it into three pieces and print the handle sides semi-flat with added supports.



Other Scale Figures, Miniatures, & Statuettes:
Figures, parts, and other miscellaneous items that don't fit the standard 5.5" scale Character Options range of figures.

Math lesson for anyone wanting to convert between different scales: This is pretty simple if you know the scale you're coming from and the scale you're going to, just divide the scale you want to print in (1:6) by the scale the model is in now (1:9) and that will give you the amount all three dimensions of your model need to be increased by (example: 6 ÷ 9 = 1.5 or 150%) Below is a handy chart for how to convert between the various Doctor Who toy scales:

multiply dimensions of all pieces by....
to 12” scale To 8” scale To: 5.5” scale To 3.75” scale
From 12” Big Chief/Product Enterprise scale (1:6) n/a 0.6667 0.4583 0.3125
From 8” Mego scale (1:9) 1.5 n/a 0.6875 0.4688
From 5.5” Character Options Scale (approx 1:13) 2.1818 1.4545 n/a 0.6818
From 3.75” Character Options/Eaglemoss scale (approx (1:21) 3.3 2.1333 1.4667 n/a

Most slicer programs will allow you to adjust the scale of parts, but if yours does not, Chitubox is free and simply to use. You can even hit the File>Save As button to re-save the STL files at their new scale for later printing or editing.



Palitoy Talking Dalek Replacement Parts
by Robert Green

Download: https://www.thingiverse.com/thing:4567634
Notes: Robert has used these parts to restore the appendages from a vintage 1975 Palitoy Talking Dalek. (Which were notoriously easy to lose) You can watch a YouTube video of his progress here.


1:6 Scale 3rd Doctor Head
by David Turner

Download: https://drive.google.com/file/d/1Zm1WILTArqb1Il2HfB3bB7PggFGLiBan/
Notes: The first of what will hopefully be many 1:6 Big Chief scale heads designed by David Turner.
Note that it is still possible to print this at Character options 1:13ish scale, just reduce it by 44% in your slicer program before printing. (If you're printing resin, because there usually is some shrinkage, you may need to print a couple between about 43% and 48% to see which lines up best with whatever body you're using. )

1:6 Scale Tloxtl Head from The Aztecs
by David Turner

Download: https://drive.google.com/file/d/1JqIZ_hyrgpa9sSYAQxtepNaXjHEpGgua/
Notes: Another great 1:6 Big Chief scale head designed by David Turner.
Note that it is still possible to print this at Character options 1:13ish scale, just reduce it by 44% in your slicer program before printing. (If you're printing resin, because there usually is some shrinkage, you may need to print a couple between about 43% and 48% to see which lines up best with whatever body you're using.)



1:6 Scale Mavic Chen Head from The Daleks' Master Plan
by David Turner

Download: https://drive.google.com/file/d/1ROqqb5SzB_-I_Rn9Qb_4c4XGYVdsHEgx/
Notes: Another great 1:6 Big Chief scale head designed by David Turner.
Note that it is still possible to print this at Character options 1:13ish scale, just reduce it by 44% in your slicer program before printing. (If you're printing resin, because there usually is some shrinkage, you may need to print a couple between about 43% and 48% to see which lines up best with whatever body you're using.)

1:6 Scale Meddling Monk Head from The Time Meddler
by David Turner

Download: https://drive.google.com/file/d/1P9WOcGyIwZBaoa_JwlTUxXrZ0ZGsTWa_
Notes: This is the original 1:6 Big Chief scale version of the head that was used in the 5.5" scale remix.
If for some reason, you want to do a 5.5" custom and only want the head, you should probably go with the remix version since it includes a neck and has a hole for a peg mount.




Full Scale Props and Costume Pieces:
Replica props and costume pieces for all your cosplay needs.

Missy's Gadget from Death In Heaven
by Stuart Galloway

Download: https://www.thingiverse.com/thing:1003036



Romana's Sonic Screwdriver from The Horns of Nimon
by Stuart Galloway

Download: https://www.thingiverse.com/thing:979881

Metebelis III Crystal from The Green Death and Planet of Spiders
by Stuart Galloway

Download: https://www.thingiverse.com/thing:857681

Rose Tyler Dalek Blaster from The Stolen Earth
by AprilStorm

Download: https://www.thingiverse.com/thing:240398

Full Sized New-Series Dalek
by Matt Palulis (and others)

Download: https://www.thingiverse.com/thing:2576488

Notes: While this is jaw-dropping gorgeous, please note that Matt printed these things on two different custom-built printers, with significantly larger build areas than most people have at home. However, if you're building a Dalek and looking for specific parts to complete your design, this is a good place to pick up bits that you don't feel like fabricating or buying online.

6th Doctor's Sonic Lance from Attack of the Cybermen
by Various

Edward Baum LED version: https://www.thingiverse.com/thing:3446209
David Dunlap version: https://www.thingiverse.com/thing:4493652
Stephen Miller version: https://www.thingiverse.com/thing:2454850

Notes: Several individuals have taken a stab at recreating this prop, but nobody seems to have gotten the proportions exactly right yet. (To be fair, there aren't many good source images.) Edward Baum's version is a hollow clamshell design with a functional button for triggering an internal LED, though I think David Dunlap's version is slightly closer to replicating the overall shape correctly, though none of them include the thumb slider on the right-hand side.


Romana I's Dress Clasp from The Ribos Operation
by Edward Baum

Download: https://www.thingiverse.com/thing:2899190

Gallifreyan Staser Rifle from Day of the Doctor/Hell Bent
by Ron Goldberg

Download: https://www.thingiverse.com/thing:3012681 (Files have been removed)

Notes: This turns into an absolutely gorgeous prop when professionally sanded, assembled, and painted. (Image below courtesy of Agents of Chaos design) Sadly, it appears the designer has deleted his thingiverse account, so unless I can get his permission to repost the files elsewhere, this design is currently unavailable.

Cyberman Gun from Earthshock/The Five Doctors/Attack of the Cybermen
by Ron Goldberg

Download: https://www.thingiverse.com/thing:3019941 (Files have been removed)

Notes: Another gorgeous prop, but like the Staser Rifle, the designer has deleted his thingiverse account, so unless I can get his permission to repost the files elsewhere, this design is currently unavailable.

Alien Coins from Planet of Fire
by Wim Ruijter

Download: https://drive.google.com/drive/folders/1Ao-qcWW0OTbO6BVx99WSpjrySdUfs0PL

Gallifreyan Staser Pistol from Day of the Doctor/Hell Bent
by David Dunlap

Download: https://www.thingiverse.com/thing:4203690

Notes: This prop is designed to be printed in two halves directly on your build plate (or borosilicate glass plate), no raft necessary.

Dalek Projenitor from Victory of the Daleks
by Stephen Miller

Download: https://www.thingiverse.com/thing:3202041

Notes: This prop is a single solid piece, ideal for resin printers. If you are filament printing, you may want to consider splitting it into two halves and printing it directly on your build plate (or borosilicate glass plate) without a raft to minimize overhangs.

Home Box from Time of the Angels
by Stephen Miller

Download: https://www.thingiverse.com/thing:2926562

Notes: This prop is a single solid piece, but because it's quite large and contains two concave depressions, you will probably want to split it into chunks so that all depressions are printed facing upwards and there are no overhangs.
Personally, I would slice the cube into four separate pieces: The side that has River's writing (about midway between the edge and the rim of the circle), the same on the opposite side that doesn't have writing, then the rest of the box split lengthwise the other direction through the center of the ridged part in the middle. This will make sure that all major surface detail is printed facing upwards for maximum quality.

Siege Mode TARDIS from Flatline
by Stephen Miller

Download: https://www.thingiverse.com/thing:2400518

Notes: All six sides are pre-cut to be printed separately. This may even be small enough to fit on resin printers.

Full-Sized K-9
by Ian Hughes

Download: https://onedrive.live.com/?cid=bb21259d5a1270f4&id=BB21259D5A1270F4%21245158&authkey=!AAF7fDRdRBs8g0w
Or files can also be found in the files section of the K-9 Builder's Group: https://www.facebook.com/groups/196432204531886/permalink/799219040919863

Notes: This is probably one of the most epic 3D printer builds ever, and unlike the 3D printed full-scale Dalek above, Ian's version should be fully printable from a regular sized home 3D printer. It'll just take a really long time and a ton of filament. On the plus side, when you're finally done printing several months from now, you'll have a gorgeous full-scale Timelord's best friend, who's incredibly light weight, durable, and includes all the mounts you need to add motors to make him fully remote controlled!
As this is a build not to be undertaken lightly, I highly recommend checking out the K-9 Builder's Group on Facebook first, to get a better undetstanding of what other builders have done before you, and how massive a dent it'll put in your wallet.

First Doctor's Sonic from Lego Dimensions
by CaptainJimiPie

Download: https://www.thingiverse.com/thing:4755395

Notes: Based off the version from the Lego Dimensions video game.

Full-Sized Cybermen Helmets
from The Tenth Planet, Wheel in Space, The Invasion, and Earthshock

by Paul Lawrence-Jennings

Download:

The Tenth Planet Cyberman: https://www.thingiverse.com/thing:4726600
Wheel In Space Cyberman: https://www.thingiverse.com/thing:4726613
The Invasion
Cyberman:
https://www.thingiverse.com/thing:4726621
Earthshock Cyberman: https://www.thingiverse.com/thing:4726469

Notes: These helmets have been parted out into smaller pieces to fit on more modern-sized 3D printers.


The Master's TCE from Spyfall
by Rob Ackers

Download: https://drive.google.com/file/d/10qTRwvidVCk0gJr2VfaVCUxXtfNppaPU

Notes: The updated Tissue Compression Eliminator used by the Sacha Dhawan version of The Master from Spyfall.

War Master's Laser Screwdriver from Rage of the Timelords
by Rob Ackers

Download: https://drive.google.com/file/d/1Ju52C2tZH9jCItSrwovw80KGRrbCGrur

Notes: The War Master's Laser Screwdriver as seen on the cover of the Big Finish audio drama Rage of the Timelords.

The Rani and Tetrap Bracelet from Mark of the Rani and Time and the Rani
by Jason McLachlan

Download: https://www.thingiverse.com/thing:4632692

Notes: This is a bit of a cheat since it's technically a Blake's 7 prop... but one that got reused at least twice on Doctor Who by The Rani and her Tetrap minions. The Doctor Who version has a slightly different button face stuck over the top of the preexisting control panel, but it should be rather easy to alter.

If you're a Blake's 7 fan, he's got the Liberator Teleport Bracelets too, as well as an incredible assortment of Star Wars and Comic Book related costume props.



Cybermat from Wheel In Space
by Stephen Roberts

Download: https://www.thingiverse.com/thing:2938647

Notes: This template isn't fully screen accurate, but is designed for remote control and light support.

The Master's TCE from Colony in Space and Claws of Axos
by Rob Ackers

Download: https://drive.google.com/file/d/18CaZQEbTW_xF7NN4kI5hw0b_qnnZ9n58

Notes: The version of the Tissue Compression Eliminator used by Roger Delgado in Season 9.

Neural Relay from Hell Bent
by Rob Ackers

Download: https://drive.google.com/file/d/1SQbAB_Pn9cKFQJGIER7bfdkwjgnlfB6P

Notes: The mind-wiping neural relay device used by The Doctor and Clara in Hell Bent.

Adipose Pill Pendant from Partners in Crime
by Rob Ackers

Download: https://drive.google.com/file/d/1GF_hC2W3Te14kjZjzfoC8A6QFTnW0B_S

Notes: Not to be taken internally.

Sonic Screwdriver from Dark Eyes and Doom Coalition
by Rob Ackers

Download: https://drive.google.com/file/d/1GLQbp5rfc9jeI6ZCWu3qRH3oEmuA7VzM

Notes: The sonic screwdriver used in the Big Finish audio series Dark Eyes and Doom Coalition.



7th Doctor Signal Detector from Ghostlight and Dimensions in Time
by Rob Ackers

Download: https://drive.google.com/file/d/1OiJpybUwzpEjEvKPnt-Vhb2UZC-I7MaU

Notes: Requires a telescoping magnetic pickup as the antenna.



Movellan Virus Capsules from Ressurection of the Daleks
by Rob Ackers

Download: https://drive.google.com/file/d/1bCPIEJlfSa9Fa-opJuuMP3KcCyisjosm

Notes: Comes in both clean and damaged variants.

TARDIS Tool Kit from Earthshock
by Rob Ackers

Download: https://drive.google.com/file/d/1UzRdS-04OmQfY21y4YUiWcYdJsJgmFSa

Notes: Currently untested.

7th Doctor's Spoons from Time and the Rani
by Rob Ackers

Download: https://drive.google.com/file/d/1EcCVeHuh2hb940-NoPD_MUV5UjLQ93Po

Notes: This must be printed flat on a filament printer so the plastic can be heat formed to make the spoon shape.

Division Badge from Survivors of the Flux/The Vanquishers
by Rob Ackers

Download: https://drive.google.com/file/d/1biuy9_dIKrflHrcCr3jVlWqLCg-ONKfQ



13th Doctor Fob Watch from Survivors of the Flux/The Vanquishers
by Rob Ackers

Download: https://drive.google.com/file/d/1jJRtTmNOSi9TCfpdVmsRxIkOuIGBOVy_



Key to Time from The Armageddon Factor
by Dan Liwszyc

Download: https://drive.google.com/file/d/1t5vehJbnApIBe0e96cKDvVaDj5x1jyAI/

Notes: This is the full-scale 1:1 prop, designed to be printed out of transparent resin. However, the pieces will not fit on a standard sized resin printer, and the largest pieces (segments 1 and 5) just barely fits on the build plate of the Phrozen Transform, which is currently the largest home use resin printer on the market.
Assuming you already had a $3000 printer large enough to handle the print job, this would be incredibly costly to print solid, assuming the suction force didn't rip it off the build plate after the first couple of layers. If you want to reproduce the Key to Time prop, your best bet would be to try to print the pieces out of regular PLA filament so you get the basic shapes, sand then down nice and smooth to remove the layer lines, then take inverse plaster or silicon molds of the pieces and fill those molds with off-the-shelf clear epoxy resin. It will take some skill to do this without a single air bubble, but it would be cheaper and better looking in the long run. Plus you then have the molds handy to make more or pass them on to somebody else.



Doctor Who and all related IP rights belong to the BBC. This is a not-for-profit fan site for personal entertainment purposes only.
No copyright infringement intended.
